Basic Specifications
Heating Type
Circulating Heat
Max Outlet Temp
60 Celsius Degree
Heating Capacity
3.5kw to 9kw
Certification
CE, ISO9001, CCC, RoHS, SASO
Production Capacity
50 Units/Day
Application
Villa Family, Sauna, Swimming Pool, Hotels, Factory Hospital, Student Apartments
Specification
650mm*320mm*500mm
Product Features & Highlights
- Panasonic compressor and R410a refrigerant
- Chinese No.1 brand shell & tube heat exchanger
- Built-in water pump for easy installation
- Japan "Saginomiya" electronic expansion valve
- User-friendly LCD controller
- 18-month warranty after delivery
Parameters Table (A01H Series)
| Rated Heating capacity (KW) |
3.5 |
5 |
7 |
9 |
| Rated outlet hot water quantity (L/H) |
75 |
108 |
150 |
193 |
| Outlet water rated/max temp (ºC) |
55 / 60 |
| Electricity Parameters |
| Rated |
Power (KW) |
0.9 |
1.24 |
1.71 |
2.26 |
| Current (A) |
4.1 |
5.6 |
7.8 |
11.4 |
| Power supply |
220V~/50HZ |
| Dimensions (mm) |
930*360*560 |
1000*360*630 |
| Weight (KG) |
43 |
51 |
61 |
64 |
| Compressor Type |
Panasonic Rotor type |
|
| Pressurized Water Tank Details |
| Capacity |
150L |
200L |
300L |
500L |
| Concurrent User |
3-4 people |
4-5 people |
6-8 people |
10-13 people |
* Testing condition: Side initial water temp: 15ºC, end water temp: 55ºC, dry-bulb temp: 20ºC, wet-bulb temp: 15ºC.
Heat Pump, Air Source Heat Pump, Air to Water Heat Pump, Home Use Heat Pump, Commercial Use Heat Pump, Water Source Heat Pump, Water to Water Heat Pump, Ground Source Heat Pump, Geothermal Heat Pump, Domestic Use Heat Pump, EVI Heat Pump, Made In China.
Frequently Asked Questions
What is the range of heating capacity for these units?
The heating capacity ranges from 3.5kW to 9kW, making them ideal for domestic and small commercial applications.
Which compressor brand is used in this heat pump?
These units are equipped with high-quality Panasonic rotor-type compressors for high efficiency and durability.
What is the maximum water temperature the system can produce?
The system can provide a rated outlet hot water temperature of 55°C, with a maximum outlet temperature of up to 60°C.
Is the heat pump suitable for outdoor installation?
Yes, it has a waterproof grade of IPX4 and is designed to operate in common heat pump work environments.
What type of refrigerant does this system use?
The system utilizes R410A refrigerant, which is efficient and commonly used in modern air source heat pumps.
What kind of maintenance or components are built-in?
The unit features a built-in water pump and a Japanese Saginomiya electronic expansion valve, along with an LCD controller for easy monitoring.
